SSH
SSH stands for "Secure Shell." It is a cryptographic network protocol used to securely access and manage network devices and servers over a potentially unsecured network.
SSH provides a secure way to establish a remote connection to a system, allowing users to execute commands and manage files on a remote machine as if they were physically present at the computer.
Requirements
You need to have an SSH key added to your Bitbucket project.
Solution
List all SSH keys
ls ~/.ssh/
Output
calaca@calaca-PC ~/var/www $ ls ~/.ssh/
config id_ed25519 id_ed25519.pub known_hosts ssh_key_adc ssh_key_adc.pub
Check the content
Select the desired SSH key and review its contents.
cat ~/.ssh/ssh_key_adc.pub
Output
calaca@calaca-PC ~ $ cat ~/.ssh/ssh_key_adc.pub
ssh-ed25519 ABADC3NzaC1l0DI1NTE5AAAAIMWf5MaychLIR0mbAvXfpy9IPvrczLr55WTZUu3Tqad email@myemail.com
Create a SSH config file
touch ~/.ssh/config
Understand the configuration
In this step, we'll use the Bitbucket project clone link. In my example, I'll use the following clone link
git@bitbucket.org:my_organization_name/my_app.git
Open the SSH config file
code ~/.ssh/config
I used VS Code Studio
to open it, however, you can use your favorite text editor.
Configure the SSH Key config file
Basically, the ssh key config
file has 03 components: Host
, HostName
and IdentifyFile
.
Let's start with the easiest: HostName
.
HostName
Since we're configuring Bitbucket, our HostName
is the following:
HostName bitbucket.org
The previous and the following code snippets must be inside the ~/.ssh/config
file.
IdentifyFile
Here, we're going to insert the path of our private ssh key.
IdentityFile ~/.ssh/ssh_key_adc
So far, we have the following code inside the ~/.ssh/config
file.
HostName bitbucket.org
IdentityFile ~/.ssh/ssh_key_adc
Host
The Host
can be virtually anything you want, but I recommend using something like the following:
Host bitbucket.org-work_adc
When you use SSH to connect to a remote server, you typically use the server's domain name or IP address.
However, with this configuration, you're creating an alias for the host configuration that you can use in your SSH commands.
So far, our code looks something like the following:
Host bitbucket.org-work_adc
HostName bitbucket.org
IdentityFile ~/.ssh/ssh_key_adc
Review SSH config file
The following is the complete code:
Host bitbucket.org-work_adc
HostName bitbucket.org
IdentityFile ~/.ssh/ssh_key_adc
Modify the clone link
A bitbucket clone link looks like the following:
git@bitbucket.org:my_organization_name/my_app.git
In order to use our ssh key, we'll have to change that link slightly based on the Host
info. The new link would be like the following:
git@bitbucket.org-work_adc:my_organization_name/my_app.git
The reason for the change is due to the content of the ~/.ssh/config
file:
Host bitbucket.org-work_adc
HostName bitbucket.org
IdentityFile ~/.ssh/ssh_key_adc
With this configuration, you're creating an alias for the host configuration that you can use in your SSH commands.
Let's modify the bitbucket clone link in order to apply that, the new bitbucket clone link is going to be:
git@bitbucket.org-work_adc:my_organization_name/my_app.git
Clone the project
git clone git@bitbucket.org-work_adc:my_organization_name/my_app.git
Open the folder's project
In my example
cd var/www/my_project_name
Check user associated with repo
git config --list
Output
Being more specific about the user
git config --list --local
The command git config --list --local
is used to display the Git configuration settings for the current Git repository at the local level. It specifically lists the configuration settings that are specific to the repository where you run the command.
Remove user associated with repo
git config --local --unset user.email
git config --local --unset user.name
Add new user
git config --local user.name "My new name"
git config --local user.email "my-new-email@email.com"
Check repo info
git config --list --local
Celebrate
You've made it!
Let's become friends
Final thoughts
I hope this article has been helpful to you. Please feel free to reach out if you have any questions. Your thoughts, suggestions, and corrections are more than welcome.
By the way, don't hesitate to drop your suggestions for new blog articles.
I look forward to seeing you next time
